Semi / Fully Automatic

Formech TF750 reel-fed vacuum former

The TF750 is Formech’s mid-sized industrial automated vacuum forming machine using reel or sheet materials, balancing substantial forming capabilities with size and footprint.

With a maximum sheet size of 750x540mm, and a forming area of 700x500mm, the TF750 is versatile enough for large and small thermoforming production lines.

It comes with a range of high-end features as standard, such as Plug Assist, pneumatic clamping, table, and heater drive with ceramic elements, cooling system, vacuum tank, safety light curtain, remote connectivity, and an extensive range of options.

Pneumatic table with speed regulator
This useful feature lifts the tool table quickly and precisely, providing effortless operation, even with heavy tools.

Ceramic heaters
Ceramic heaters are well suited for high volume production when heaters are engaged for long periods and constant temperature must be maintained.

Pre-stretch
Pre-stretch pumps air into the heated sheet, creating a bubble to avoid thinning of material with deeper tools.

What's included?

A table mesh
12mm push-in tube fitting on machine (connected to 1/2" BSP regulator)
3m x 12mm pipe supplied with 12mm push-in to 1/2" BSPT fitting
Approx. 5m Flying lead, with exposed conductor wires to connect to mains power box
Pneumatic Plug Assist
12 months warranty

Video Library
Watch our automatic models in action on our YouTube channel.

Request a quote now
With so many options and accessories, Formech TF Series vacuum forming machines can be configured in multiple ways. We will advise on the right set-up for your products and projects, run tests on your tooling and materials, then create a bespoke quote based on your requirements and needs. Typical delivery time is 8-10 weeks from payment.

Download spec sheet

Please request a quote to set-up a consultation about your requirements

SKU: m14-01-1

Request a quote

Compare

Formech TF750 reel-fed Features

Ceramic heaters

Vacuum & release

Vacuum & pressure gauges

PLC Control with 10" hi-res touch screen

FCV (Formech Cycle View) with 40 programme memory

16 independently controllable heating zones

Reel feed

Pre-stretch

Auto-level

Twin cooling fans

Vacuum receiver tank

Pneumatic table with speed regulator

Pneumatic heater drive

Table height adjust

Multi user pin access control

Pneumatically powered clamping frame (hinged)

Safety light curtain

Plug assist with speed regulator

Heater / table interlock override

Illuminated view windows

Digitally controlled flow valve - vacuum

Oil filled rotary vane pump 18m3/h

12 months warranty

Optional extras

Customise your vacuum former

Negative gate for Formech TF750

Reducing windows for Formech TF750 (custom size)

Spray mist for Formech TF750

Cooling bolster for Formech TF750

Heating pyrometer for Formech TF750

Cooling pyrometer for Formech TF750

Upgrade to 26 heating zones for Formech TF750 (single heater)

Twin heater option for Formech TF750

Servo plug assist for Formech TF750

Upgrade cooling system for Formech TF750

Servo table for Formech TF750

Digitally controlled flow valve - pneumatic table (TF750)

Digitally controlled flow valve - pre-stretch & auto-level (TF750)

Digitally controlled flow valve - release (TF750)

Clear material sensing for Formech TF750

FA remote connectivity (FRC)

Spare parts kit for Formech TF750

Spare parts kit for Formech TF750-T

Digitally controlled flow valve - pneumatic plug (TF750)

Formech RP1200 Roller Press

Formech RP700 Roller Press

TF750 Technical specifications

mm in

Forming capacity

Forming area	700 x 500 mm
Sheet size	750 x 540 mm
Max depth of draw	350 mm
Max material thickness	6 mm

Dimensions

Machine width	3677 mm
Machine height	2576 mm
Machine depth	2600 mm
Machine weight	1150 kg

Power

Power consumption (kW)	11
3 Phase power requirements	380-415V / 32A

Air

Air requirements (PSI/bar)	87 / 6
Operating interface	9.7" Colour HMI
Vacuum pump type	Oil filled rotary vane pump
Pump flow (SCFM @ 0 in. / 60Hz)	15.9
Pump flow m3 /h @ 0mbar / 50Hz	23.5
Mould release method	External air supply

Heating

Heater type	Ceramic
Heating zones	16

Fully-automatic Formech machine features and specifications are subject to change without notice as part of our continual product development program
